Application
Police, Bomb disposal squads,VIP protection, Special Police (S.W.A.T), military security forces, bombsquads, anti-terror units, anti-drug units, Border control units, checkpointpersonnel, Meeting room, Hospitals, Banks, Church, Conference Rooms, Classroomsand so on, such types of law enforcement personnel who benefit greatly from thedeployment of any state in the art portable RF jamming solutions, who canconduct the law enforcement process more effectively to reduce the chance thatthe criminals leak the information.
TechnicalParameters
A:Jamming range: Radius:5~20m (-75dBm, depending on the distance of base station)
B:Transmission power: ≥5W
C:Jammed signal type: 4G(TD-LTE, TD-FDD), 3G(TD/WCDMA/CDMA2000), 2G:GSM900(Mobile/Unicom 2G), CDMA(Telecom), DCS1800(Mobile/Unicom 1800M),GPS L1(Civilsatellite navigation）
D: Increasable signaltype: Wi-Fi（5.8G）, GPS L2（Militarynavigation）, Bluetooth；Or customized according to the national frequency band
E:Output channel: eightchannels output，Selective jamming todifferent mobile phone systems
Features
Small volume:The hand-helddesign can be mastered with one hand, slightly larger than the commonly usedwalkie talkie
Portable:8 channel signaljammer can be put into a pocket or satchel, and can be hung or worn on the armand belt
Big power:wireless signaljammer can effectively shield all commonly used mobile phone signals and WiFisignals within a radius of 5~20 meters
Stability:exquisiteventilation and heat dissipation design, even if the machine is turned oncontinuously for 2 hours, the temperature of the shell will not exceed 45 ℃
Battery powered:Safe lithiumiron phosphate large capacity battery, can be recharged and used repeatedly,and the battery can be quickly removed and replaced
Speciality:With bandselection switch, Signal Shield can selectively shield mobilephones of different systems
Personalizedcustomization:According to different countries, regions or shieldingrequirements, different Signal Shield System types arecustomized
Detailed Technical Parameter
Band Parameter | Channel | Frequency | Average output power |
CDMA | 869-894MHz | 0.5～1W | |
GSM | 925-960MHz | 0.5～1W | |
DCS/ FDD | 1805-1920MHz | 0.5～1W | |
LTE4G，2300 | 2300-2400MHz | 0.5～1W | |
LTE4G，2600 | 2500-2690MHz | 0.5～1W | |
WCDMA | 2110-2170MHz | 0.5～1W | |
WIFI/Bluetooth | 2400-2500MHz | 0.5～1W | |
GPS L1 | 1575.42MHz | 0.5～1W | |
Size | 192x90x45 | ||
Total weight | Net weight：0.74Kg/Gross weight：2.2Kg | ||
Ambient temperature | -10-50℃ | ||
Relative humidity | 5-80% | ||
Transmission power | ≥5W | ||
Power input | AC 100V-240V/DC 12V | ||
Built in battery | 3000mA/h、Lithium iron phosphate battery | ||
Working hours | 60-90 Minute | ||
Considerations
Be sure to connect all the antennae before the power supply is switchon.
Try to recharge the device only once battery is run-out when you getthe device in the first time.
With the increase of charging electricity, charging indication lightturns dim and finally goes off once it is fully charged.
Don't put the jammer into the water or fire to avoid using in the badCondition like over-wet, over-hot, high voltage and high magnetism.
Any sealed mark on the machine tore is invalid.
Antennae shall be put vertical to the ground to get more efficientjamming performance.
OEM Customized Service
Frequency spreading can be done for Wi-Fi, Bluetooth, Intercom andwireless data transmit etc.
More than 50 units can provide screen printing OEM service.
Provide neutral device.
